Panasonic AK-PLV100GSJ 4K PL-Mount Super 35 Studio Camera

Panasonic AK-PLV100GSJ 4K PL-Mount Super 35 Studio Camera

The Panasonic AK-PLV100GSJ is a 4K studio camera built around a 5.7K Super 35 mm image sensor and a 35 mm PL lens mount. It gives live production the shallow depth of field and look of a cinema camera while keeping the handling, CCU control and intercom of a conventional studio camera. This is the LEMO connector model.

For studio camera users, the camera head is compatible with Panasonic AK-UCU700 and AK-HCU250 camera control units, so an existing system can swap in the AK-PLV100GSJ head and start shooting cinematic live video. For cinema camera users, it removes the usual rig of external converters: the head outputs 12G-SDI and 3G-SDI directly, and in an ST 2110 system it can run without a CCU at all. It can also be integrated with the Panasonic KAIROS IT/IP platform for remote production.

Picture tools include Dual Native ISO 800/2500, V-Log with 14 stops of dynamic range, FILM-REC gamma, a motorized ND filter (Clear, 1/4, 1/16, 1/64), a 2x digital extender, DRS, skin tone detail correction and 12-axis color correction. Contact CINEOM Broadcast FZCO for a quote or technical advice on building an AK-PLV100GSJ camera chain.

Key Features

• 5.7K Super 35 mm image sensor, 17.25 million pixels
• 35 mm PL mount for cinema prime and zoom lenses
• Dual Native ISO 800/2500, V-Log with 14 stops of dynamic range and FILM-REC gamma
• Motorized ND filter: Clear, 1/4, 1/16, 1/64
• UHD 3840×2160 and HD 1920×1080 at 59.94p, 50p, 29.97p, 25p and 23.98p
• SDI OUT1 at 12G/6G/3G/1.5G-SDI and SDI OUT2 at 3G/1.5G-SDI from the camera head
• Optical fiber connection to CCU for long-distance transmission, plus 3G-SDI trunk and prompter
• Digital extender (2x), DRS, focus assist, skin tone detail, linear matrix and 12-axis color correction

Best Suitable For / Use Cases

• Live concerts and stage shows that want a cinematic, shallow depth of field look
• Live sports coverage needing a feature camera alongside standard studio cameras
• Studio and OB systems already built on Panasonic AK-UCU700 or AK-HCU250 CCUs
• ST 2110 IP productions running a single camera without a CCU
• Remote production workflows using the Panasonic KAIROS platform

Paired With

• Panasonic AK-UCU700 / AK-UCU710 4K/IP camera control unit
• Panasonic AK-HCU250 camera control unit (latest software required)
• Panasonic AK-HRP1010GJ remote operation panel
• Panasonic AK-HVF100GJ 9-inch LCD color viewfinder
• Panasonic AK-MSU1000GJ master setup unit

FAQs

What sensor and lens mount does the AK-PLV100GSJ use?

It uses a 5.7K Super 35 mm sensor with 17.25 million pixels and a 35 mm PL mount, so it takes cinema-style PL lenses.

Does the AK-PLV100GSJ need a CCU?

No. The camera head outputs 12G-SDI and 3G-SDI directly, and in an ST 2110 system it can operate without a CCU. It can also be connected to an AK-UCU700/UCU710 or AK-HCU250 CCU over optical fiber.

Can it work with my existing Panasonic CCU?

Panasonic lists compatibility with the AK-UCU700/UCU710 and the AK-HCU250. The AK-HCU250 requires the latest software version.

What are the weight and dimensions?

The body weighs approximately 4.2 kg and measures 151 x 267 x 389 mm (W x H x D), excluding protrusions and accessories.

Where can I buy the Panasonic AK-PLV100GSJ?

The AK-PLV100GSJ is available through CINEOM Broadcast FZCO, serving the Middle East, Africa, Asia and Europe from Dubai. Contact the team for pricing and system configuration advice.
