Panasonic AK-UCX100 4K Studio Camera with ST 2110, NDI and SRT

Panasonic AK-UCX100 4K Studio Camera with ST 2110, NDI and SRT

The Panasonic AK-UCX100 is a 4K studio camera for IP-era live production, aimed at studio work, sports broadcasting and stage productions. It resolves 2,000 TV lines horizontally and vertically in 4K and supports High Dynamic Range in the HLG format to BT.2020, with HDR and SDR (BT.709) output at the same time. This is the LEMO connector model with a 2/3-type bayonet lens mount.

The camera head can run standalone without a camera control unit. It has two 12G-SDI outputs and two SFP28 ports and supports SMPTE ST 2110, NDI High Bandwidth and SRT. ST 2110 brings network redundancy and JPEG XS compression for low-latency, visually lossless transport. When a full fiber chain is needed, it connects to the AK-UCU700 or AK-UCU710 CCU or the AK-CFA100 camera fiber adaptor.

Panasonic lists a focus assist function, an autofocus function built into the camera head delivered by firmware, moire reduction, 4K 2x and HD 4x high-speed shooting, and new LED color adjustment tools (Color Temp. Blend, Target Color Correction and Chroma Suppression) scheduled for a firmware update. Contact CINEOM Broadcast FZCO for a quote or technical advice on an AK-UCX100 system.

Key Features

• 19.29 million pixel MOS sensor, 2/3-type bayonet lens mount
• 4K: 2000 TV lines, HD: 1000 TV lines (center), S/N 62 dB
• Simultaneous HLG (BT.2020) and SDR (BT.709) output
• Two 12G/6G/3G/1.5G-SDI outputs plus trunk input and genlock
• Two SFP28 ports for SMPTE ST 2110 with JPEG XS, NDI High Bandwidth and SRT
• Runs standalone without a CCU, or with AK-UCU700/UCU710 and AK-CFA100
• ND filters Clear, 1/2, 1/4, 1/16, 1/64 and FX filters including Cross and Diffusion
• 4K 2x and HD 4x high-speed shooting, moire reduction and integration with Panasonic PTZ cameras

Best Suitable For / Use Cases

• Studio production moving from SDI to SMPTE ST 2110
• Sports broadcasting that needs high-speed 4K and HD capture
• Stage productions and concerts shot in HDR with a simultaneous SDR feed
• Compact IP or NDI productions using the camera head without a CCU
• Remote production over SRT

Paired With

• Panasonic AK-UCU700 / AK-UCU710 4K/IP camera control unit
• Panasonic AK-CFA100 camera fiber adaptor
• Panasonic AK-HRP1010GJ remote operation panel
• Panasonic AK-HVF100GJ 9-inch LCD color viewfinder
• Panasonic AK-HBU500 camera build-up unit for large studio lenses

FAQs

Does the AK-UCX100 need a CCU?

No. It can operate as a standalone camera head with two 12G-SDI outputs and IP output over SMPTE ST 2110, NDI High Bandwidth or SRT. A CCU such as the AK-UCU700/UCU710 can be added for a fiber chain.

Which lens mount does it use?

The AK-UCX100 uses a 2/3-type bayonet mount, so it takes standard broadcast zoom lenses. The AK-HBU500 build-up unit supports large studio lenses.

Does it support HDR?

Yes. It supports HLG to BT.2020 and can output HDR and SDR (BT.709) at the same time.

What are the weight and dimensions?

The body weighs approximately 4.55 kg and measures 157 x 267 x 371.5 mm (W x H x D), excluding protrusions.

Where can I buy the Panasonic AK-UCX100?

The AK-UCX100 is available through CINEOM Broadcast FZCO, serving the Middle East, Africa, Asia and Europe from Dubai. Contact the team for pricing and IP system planning.
